Autumn 2018 European Energy Innovation 43
BATTERY INNOVATION
In addition, these compounds can
be toxic and are not environmentally
benign. Consequently, there has been
a steady increase in research on
organic active materials for batteries
over the last couple of years.
At present, the only available H O + NaCl H O + NaCl
commercial Redox-Flow Batteries 2
(RFBs) technology is the vanadium HO
RFB, which uses vanadium salts It is safe as it has no fire or explosion
as active materials that are then Blue Battery hazard, and it can be built on every
dissolved in concentrated sulfuric scale (kWh-MWh-GWh) as well as
acid. These solutions, the so-called new and pioneering metal free RFB without geographical constraints.
electrolytes (anolyte and catholyte) will be used to operate salt caverns The Blue Battery has a very distinct
are stored in two separate tanks. For for energy storage, essentially advantage in that the energy storage
charge and discharge of the RFB, creating the world’s largest battery to capacity is very cheap (basically salt
the electrolytes are pumped into an store green electricity. water and a reservoir). This means
electrochemical cell consisting of two that by adding additional reservoir
electrodes separated by a membrane THE BLUE BATTERY volume, the energy storage capacity
(cell stack) where the redox reactions Within AquaBattery – a Netherlands- is increased. This characteristic
are taking place. The great advantage based spin-off company from allows to charge and discharge the
of RFBs is that the power (i.e. the size Wetsus, European Centre of battery for longer periods of time.
of the membrane/cell stack) and the Excellence for Sustainable Water Therefore, discharge times of multiple
energy (i.e. the size of the storage Technology – a team of eight young hours to weeks are possible with the
tank) can be scaled independently. engineers and entrepreneurs are Blue Battery which really sets this
However, the main drawbacks of collaborating on the development of technology apart from other storage
the existing commercial V-RFBs are a novel stationary electrical energy systems.
the high cost of the active material storage system: the Blue Battery.
vanadium which is a critical raw This Blue Battery stores electricity in AquaBattery and its partners are
material. water and table salt. Electrical energy testing the first household-scale
is used to separate fresh water (1kW-10kWh) Blue Battery at The Green
To address this, CEEC Jena has from salt water during the charging Village in Delft. Different components,
developed a salt water-based phase, and with the same technology such as membrane stacks, water
polymer to replace vanadium in RFBs. electrical energy is regenerated when tanks, and pumps are upscaled and
As membranes are then cheaper, the fresh water and salt water are mixed integrated for the first time and they
polymer RFBs cost significantly less during the discharging phase. are operated autonomously on a
while also being more sustainable smart battery management system.
and easy to handle. The polymers The unique selling points of the The aim is to showcase the potential
(macromolecules) can be charged / Blue Battery compared to other of the Blue Battery in a controllable
discharged (oxidized and reduced). stationary energy storage systems are but realistic environment, and to
The macromolecules are larger in size its sustainability, availability, safety, obtain valuable insights of how it
compared to the sodium and chloride and scalability. Unlike most other functions within an electricity grid and
ions opening up the possibility to grid scale electrical energy storage
utilize size-exclusion membranes (i.e. systems, the Blue Battery does not
dialysis membrane). contain any toxic or scarce materials.
The possible application areas for
polymer RFBs are similar to other
flow battery technologies providing
many opportunities for applications
of different sizes. As an example,
CEEC Jena are currently working
together on the project brine4power
with EWE, a large German electricity
producer and provider, where this
